Tekbox EMC/RF Accessories

26 of 26 Article

TekBox TBSWR-60K500

Be the first to write a review

Tekbox VSWR bridges combine the wide frequency range and directivity of a directional bridge and the low insertion loss and power handling capability of a directional coupler.

  • Frequency range: 60 kHz – 500 MHz
  • Directivity:
    • 60 kHz – 500 MHz > 20 dB
    • 150 kHz – 300 MHz > 25 dB
    • 200 kHz – 30 MHz. > 30 dB
  • Coupling:
    • 60 kHz – 100 MHz -50 dB ± 0.7 dB,
    • 100 MHz – 500 MHz -50 dB + 0.7/- 10 dB
  • Insertion loss:
    • 60 kHz – 200 MHz < 0.15 dB
    • 200 MHz – 500 MHz < 0.6 dB
  • Max. power:
    • 60 kHz – 200 MHz 200 W CW *)
    • 200 MHz – 500 MHz 100 W CW *) *= Short time (max. 1 minute): 350 W Output shorted or open: max. 80 W
  • Operating temperature range: – 20 °C to + 40 °C
  • Impedance: 50 Ω
  • Port matching: > 20 dB
  • RF connectors, through ports: N-female
  • RF connectors, coupling ports: SMA-female
2 years warranty

Nr: TBSWR-60K500

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 879.-
net (VAT Details)
€ 1,046.01
incl. 19% VAT

TekBox TBSWR-200K500

Be the first to write a review

Tekbox VSWR bridges combine the wide frequency range and directivity of a directional bridge and the low insertion loss and power handling capability of a directional coupler.

  • Frequency range: 200 kHz – 500 MHz
  • Directivity:
    • 200 kHz – 500 MHz > 20 dB
    • 800 kHz – 50 MHz > 30 dB
  • Coupling:
    • 200 kHz – 300 MHz -40 dB ± 0.3 dB
    • 300 MHz – 500 MHz -40 dB ± 1 dB
  • Insertion loss:
    • 200 kHz – 200 MHz < 0.3 dB
    • 200 MHz – 500 MHz < 0.7 dB
  • Max. power:
    • 200 kHz – 200 MHz 100 W CW *)
    • 200 MHz – 500 MHz 70 W CW *) *= Short time (max. 1 minute): 150 W Output shorted or open: max. 35 W
  • Operating temperature range: - 20 °C to + 40 °C
  • Impedance: 50 Ω
  • Port matching: > 20 dB
  • RF connectors, through ports: N-female
  • RF connectors, coupling ports: SMA-female
2 years warranty

Nr: TBSWR-200K500

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 779.-
net (VAT Details)
€ 927.01
incl. 19% VAT

TekBox TBSWR-600K700

Be the first to write a review

Tekbox VSWR bridges combine the wide frequency range and directivity of a directional bridge and the low insertion loss and power handling capability of a directional coupler.

  • Frequency range: 200 kHz – 700 MHz
  • Directivity:
    • 600 kHz – 700 MHz > 20 dB
    • 10 MHz – 500 MHz > 30 dB
  • Coupling: 300 kHz – 700 MHz -30 dB ± 0.5 dB
  • Insertion loss:
    • 200 kHz – 100 MHz < 0.7 dB
    • 100 MHz – 700 MHz < 1.5 dB
  • Max. power:
    • 200 kHz – 200 MHz 50 W CW *)
    • 200 MHz – 700 MHz 40 W CW *) *= Output shorted or open: max. 12.5 W
  • Operating temperature range: - 20 °C to + 40 °C
  • Impedance: 50 Ω
  • Port matching: > 20 dB
  • RF connectors, through ports: N-female
  • RF connectors, coupling ports: SMA-female
2 years warranty

Nr: TBSWR-600K700

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 679.-
net (VAT Details)
€ 808.01
incl. 19% VAT

TekBox TBSWR-300K6000

Be the first to write a review

Tekbox VSWR bridges combine the wide frequency range and directivity of a directional bridge and the low insertion loss and power handling capability of a directional coupler.

  • Frequency range: 300 kHz – 6 GHz
  • Directivity:
    • 300 kHz – 700 kHz > 25 dB
    • 700 kHz – 5 GHz > 30 dB
    • 5 GHz – 6 GHz > 20 dB
  • Coupling:
    • 300 kHz – 3 GHz -20 dB ± 1 dB
    • 3 GHz – 6 GHz -19 dB ...-16 dB
  • Insertion loss:
    • 300 kHz – 1 GHz < 1.8 dB
    • 1 GHz – 6 GHz < 2.6 dB
  • Max. power:
    • 300 kHz – 6 GHz 4 W CW *) *= Output shorted or open: max. 1 W
  • Operating temperature range: - 20 °C to + 40 °C
  • Impedance: 50 Ω
  • Port matching: > 20 dB
  • RF connectors : SMA-female
2 years warranty

Nr: TBSWR-300K6000

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 579.-
net (VAT Details)
€ 689.01
incl. 19% VAT

TekBox TBESDT1

Be the first to write a review

The TBESDT1 ESD-Target is a current sensing transducer to verify ESD-Simulators. It is used to take measurements compliant with IEC 61000-4-2 up to 4 GHz.

SPECIFICATIONS

  • Compliance: IEC 61000-4-2
  • Resistance: 2.08 Ω ± 1%
  • Transfer impedance: 2 V/A - 0.2 V/A with 20 dB attenuator
  • Frequency range: DC – 4 GHz, < ± 0.5 dB up to 1 GHz, < ± 1.2 dB up to 4 GHz
  • Max. pulse amplitude: ± 30 kV
2 years warranty

Nr: TBESDT1

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 1,490.-
net (VAT Details)
€ 1,773.10
incl. 19% VAT

TekBox TBESDT2

Be the first to write a review

The TBESDT2 ESD-Target is a current sensing transducer to verify ESD-Simulators. It is used to take measurements compliant with IEC 61000-4-2 up to 4 GHz.

SPECIFICATIONS

  • Compliance: IEC 61000-4-2
  • Resistance: 1
  • Transfer impedance: 1 V/A - 0.1 V/A with 20 dB attenuator
  • Frequency range: DC – 4 GHz, < ± 0.5 dB up to 1 GHz, < ± 1.2 dB up to 4 GHz
  • Max. pulse amplitude: ± 30 kV
2 years warranty

Nr: TBESDT2

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 1,490.-
net (VAT Details)
€ 1,773.10
incl. 19% VAT

TekBox TBBNC1

Be the first to write a review

BNC accessory set:

  • 1 x BNC-male to Banana-male
  • 1 x BNC-male to Banana-female
  • 1 x BNC-female to Banana-male
  • 1 x BNC-female to Banana-female
  • 1 x BNC-male to terminal block
  • 1 x BNC-female to terminal block
  • 1 x BNC-female to BNC-male 50 Ohm feed-through adapter SWR < 1:1.5 @ 1 GHz
2 years warranty

Nr: TBBNC1

Plus Shipping Costs
in Stock
€ 45.-
net (VAT Details)
€ 53.55
incl. 19% VAT

TekBox TBCAS1

Be the first to write a review

44 x 50 Ω coaxial adapter (N type, BNC, RCA, SMA, SMB):

  • 1 x N-plug to N-plug
  • 1 x N-plug to N-plug
  • 4 x N-plug to SMA socket
  • 2 x N-plug to SMA socket
  • 2 x N-plug to SMB socket
  • 4 x N-plug to BNC socket
  • 1 x N plug to BNC plug
  • 1 x N socket to BNC plug
  • 1 x N socket to BNC socket
  • 2 x N socket to SMA socket
  • 2 x N socket to SMA plug
  • 1 x N socket to SMB socket
  • 1 x BNC plug to BNC plug
  • 1 x BNC female to BNC female
  • 1 x BNC male to RCA female
  • 1 x BNC female to RCA male
  • 2 x BNC plug to SMA socket
  • 1 x BNC female to SMA male
  • 2 x BNC socket to SMA socket
  • 3 x SMA socket on SMA socket
  • 3 x SMA plug to SMA plug
  • 2 x SMA connector on SMB connector
  • 1 x N socket on SMB socket
  • 2 x SMA plug to SMB socket
  • 2 x SMA socket on SMB socket
2 years warranty

Nr: TBCAS1
EAN: 8936120670057

Plus Shipping Costs
in Stock
€ 184.-
net (VAT Details)
€ 218.96
incl. 19% VAT

TekBox TBAS1

Be the first to write a review

The set consists the following attenuators:

  • 3 dB RF attenuator, tolerance: ± 0.5 dB
  • 6 dB RF attenuator, tolerance: ±0,5 dB
  • 10 dB RF attenuator, tolerance: ±0,5 dB
  • 20 dB RF attenuator, tolerance: ±0,8 dB
  • Frequency range: DC..3 GHz, VSWR <1,2
  • load-bearing capacity: 2 W at -55 to 70°C
  • Connections: N-plug to N-socket
2 years warranty

Nr: TBAS1
EAN: 8936120675380

Plus Shipping Costs
in Stock
€ 115.-
net (VAT Details)
€ 136.85
incl. 19% VAT

TekBox TBAS2

Be the first to write a review

The set consists of six 1 watt attenuators and two 50 Ω terminators:

  • 3 dB attenuator 1 W, tolerance: ± 0.5 dB
  • 6 dB attenuator 1 W, tolerance: ±0,5 dB
  • 10 dB attenuator 1 W, tolerance: ±0,5 dB
  • 15 dB attenuator 1 W, tolerance: ±0,5 dB
  • 20 dB attenuator 1 W, tolerance: ±0,8 dB
  • 30 dB attenuator, tolerance: ±0,8 dB
  • Frequency range: DC..6 GHz, VSWR <1,2
  • 2 x 50 Ω terminators
  • Connections: SMA-plug
2 years warranty

Nr: TBAS2
EAN: 8936120675298

Plus Shipping Costs
in Stock
€ 165.-
net (VAT Details)
€ 196.35
incl. 19% VAT

TekBox TBAS3

Be the first to write a review

The set consists of four 10 watt attenuators:

  • 3 dB RF attenuator, tolerance: ±0.5 dB
  • 6 dB RF attenuator, tolerance: ±0,5 dB
  • 10 dB RF attenuator, tolerance: ±0,5 dB
  • 20 dB RF attenuator, tolerance: ±0,8 dB
  • Frequency range: DC..3 GHz, VSWR <1,2
  • load-bearing capacity: 10 W at -55 to 70°C, bis 125°C to max. 5 W
  • Connections: N-plug to N-socket
2 years warranty

Nr: TBAS3
EAN: 8936120675434

Plus Shipping Costs
in Stock
€ 165.-
net (VAT Details)
€ 196.35
incl. 19% VAT

TekBox TBAS4

Be the first to write a review

The set consists of four 2 watt attenuators:

  • 3 dB RF attenuator, tolerance: ±0.3 dB
  • 6 dB RF attenuator, tolerance: ±0,3 dB
  • 10 dB RF attenuator, tolerance: ±0,3 dB
  • 20 dB RF attenuator, tolerance: ±0,3 dB
  • Frequency range: DC up to 6 GHz, VSWR <1,2
  • load-bearing capacity: 2 W at -55 to 40 °C, up to 70 °C with 50 % power de-rating
  • Connections: N-plug to N-socket
2 years warranty

Nr: TBAS4

Plus Shipping Costs
in Stock
€ 165.-
net (VAT Details)
€ 196.35
incl. 19% VAT

TekBox TBFL1

Be the first to write a review

General application for limiting high-energy RF pulses (Transient limiter)

  • Frequency range: 9 kHz to 600 MHz
  • Attenuation: 10 dB – 0,5/+1,2 dB in-band (9 kHz..600 MHz)
  • Attenuation highpass-filter: > 30 dB @ 2 kHz
  • Max. continuous RF input power: 5 W (+37 dBm) in-band
  • Max. DC-input voltage: ±20 V
  • Input matching, linear workspace: 9 kHz..600 MHz < -16 dB
  • Output matching, linear workspace: 9 kHz..600 MHz < -23 dB
  • Linear workspace: up to 0 dBm Eingangspegel, in-band
  • Threshold: +11 dBm (@ 37 dBm input level)
  • Connection input: N-socket, Connection output: N-plug
  • Dimensions: 156 mm x 26 mm x 26 mm
2 years warranty

Nr: TBFL1
EAN: 8936120675281

with FREE shipping within the EU! Shipping costs outside EU
in Stock
€ 329.-
net (VAT Details)
€ 391.51
incl. 19% VAT

TekBox TBTER-0.5W-2GHz-50-BNCM

Be the first to write a review

Terminator Type BNC

  • 0.5 W
  • 50 Ω
  • BNC male
  • 2 GHz
2 years warranty

Nr: TBTER-0.5W-2GHz-50-BNCM

Plus Shipping Costs
in 11-30 days after order in stock.
€ 16.-
net (VAT Details)
€ 19.04
incl. 19% VAT

TekBox TBTER-2W-3GHz-50-BNCM

Be the first to write a review

Terminator Type BNC

  • 2 W
  • 50 Ω
  • BNC male
  • 3 GHz
2 years warranty

Nr: TBTER-2W-3GHz-50-BNCM

Plus Shipping Costs
in 11-30 days after order in stock.
€ 17.-
net (VAT Details)
€ 20.23
incl. 19% VAT

TekBox TBTER-2W-6GHz-50-N

Be the first to write a review

Terminator Type N

  • 2 W
  • 50 Ω
  • N male
  • 6 GHz
2 years warranty

Nr: TBTER-2W-6GHz-50-N

Plus Shipping Costs
in 11-30 days after order in stock.
€ 23.-
net (VAT Details)
€ 27.37
incl. 19% VAT

TekBox TBTER-10W-6GHz-50-N

Be the first to write a review

Terminator Type N

  • 10 W
  • 50 Ω
  • N male
  • 6 GHz
2 years warranty

Nr: TBTER-10W-6GHz-50-N

Plus Shipping Costs
in Stock
€ 42.-
net (VAT Details)
€ 49.98
incl. 19% VAT

TekBox TBTER-25W-3GHz-50-N

Be the first to write a review

Terminator Type N

  • 25 W
  • 50 Ω
  • N male
  • 3 GHz
2 years warranty

Nr: TBTER-25W-3GHz-50-N

Plus Shipping Costs
in Stock
€ 42.-
net (VAT Details)
€ 49.98
incl. 19% VAT

TekBox TBTERFT-0.5W-1GHz-BNCF/BNCM

Be the first to write a review

Feedthrough terminator Type BNC

  • 0.5 W
  • 50 Ω
  • BNC male / BNC female
  • 1 GHz
2 years warranty

Nr: TBTERFT-0.5W-1GHz-BNCF/BNCM

Plus Shipping Costs
in 11-30 days after order in stock.
€ 10.-
net (VAT Details)
€ 11.90
incl. 19% VAT

TekBox TBJT01

Be the first to write a review

TBJT01 - Wideband Injection Transformer

Usable frequency range: 10 Hz – 45 MHz 3 dB frequency range: 15 Hz – 9 MHz typ. Characterized freq. range: 1 Hz - 100 MHz

2 years warranty

Nr: TBJT01

with FREE shipping within the EU! Shipping costs outside EU
in Stock
€ 428.-
net (VAT Details)
€ 509.32
incl. 19% VAT

TekBox TBJT02

Be the first to write a review

TBJT01 - Wideband Injection Transformer

Usable frequency range: 10 Hz – 45 MHz 3 dB frequency range: 15 Hz – 9 MHz typ. Characterized freq. range: 1 Hz - 100 MHz

2 years warranty

Nr: TBJT02

with FREE shipping within the EU! Shipping costs outside EU
in 11-30 days after order in stock.
€ 428.-
net (VAT Details)
€ 509.32
incl. 19% VAT

TekBox TBRFPS1

Be the first to write a review

General Purpose 2-Way Power Splitter/Power Combiner

Frequency range 100 kHz-800 MHz Max. power 2 W Typical mid-band performance S21 above 3 dB: -0.5 dB S31 above 3 dB: -0.6 dB Amplitude unbalance: 0.1 dB Phase unbalance: 0.1° Isolation: 23 dB SWR Port 1: 1.2 SWR Port 2: 1.2 SWR Port 3: 1.2

2 years warranty

Nr: TBRFPS1

Plus Shipping Costs
in 11-30 days after order in stock.
€ 73.-
net (VAT Details)
€ 86.87
incl. 19% VAT

TekBox TBRFPS4

Be the first to write a review

General Purpose 2-Way Power Splitter/Power Combiner

Frequency range 5 MHz-3 GHz Max. power 0.5 W Typical mid-band performance S21 above 3 dB: -0.6 dB S31 above 3 dB: -0.9 dB Amplitude unbalance: -0. dB Phase unbalance: 0.5° Isolation: 21 dB SWR Port 1: 2.0 SWR Port 2: 2.0 SWR Port 3: 2.0 Connectors: Type N

2 years warranty

Nr: TBRFPS4
EAN: 8936120670958

Plus Shipping Costs
in Stock
€ 84.-
net (VAT Details)
€ 99.96
incl. 19% VAT

TekBox TBHPF1-9 kHz

Be the first to write a review

High Pass Filter, Type N

  • 50 Ω
  • 9 kHz – 3 GHz
  • 100 V; 250 V for <5 s
2 years warranty

Nr: TBHPF1-9kHz
EAN: 8936120675243

Plus Shipping Costs
in Stock
€ 99.-
net (VAT Details)
€ 117.81
incl. 19% VAT

TekBox TBHPF1-150 kHz

Be the first to write a review

High Pass Filter, Type N

  • 50 Ω
  • 150 kHz – 3 GHz
  • 100 V; 250 V for <5 s
2 years warranty

Nr: TBHPF1-150kHz

Plus Shipping Costs
in 11-30 days after order in stock.
€ 99.-
net (VAT Details)
€ 117.81
incl. 19% VAT

TekBox TBLM01

Be the first to write a review

The TBLM01 LISN Mate can be used to measure common-mode and differential mode noise measured separately. The LISN Mate is connected to the output of a LISN which is inserted into the positive supply line, and to a second LISN connected to the negative supply line (e.g. with a (e.g. with two TBL5016-1 or two TBOH01).

2 years warranty

Nr: TBLM01
EAN: 8936120670132

with FREE shipping within the EU! Shipping costs outside EU
in Stock
€ 270.-
net (VAT Details)
€ 321.30
incl. 19% VAT
