Micsig Probes

6 of 6 Article

Micsig DP10007

1 Review

Active differential probe, switchable

Attenuation 10:1 / 100:1
Input Impedance 8 MΩ 1.25 pF （diff） / 4 MΩ 2.5 pF
Bandwidth 100 MHz
Rise Time 3.5 ns
Max. Test Input 70 V (10:1) / 700 V (100:1)
Max. Input (grounded) CAT II 600 V
Input Cable Length 0.45 m
Output Cable Length 0.90 m

  • Only connect to a grounded (earthed) oscilloscope!
Probe
max. Bandwidth
100 MHz
max. Input Voltage
700 V
Input Resistance
10 MΩ
Type
Oscilloscope
Active
Differential probe
Probe-Divider
10 : 1
100 : 1
1 year warranty

Nr: Micsig DP10007

Plus Shipping Costs
in Stock
€ 169.-
net (VAT Details)
€ 201.11
incl. 19% VAT

Micsig DP10013

6 Reviews

Active differential probe, switchable

Attenuation 50:1 / 500:1
Input Impedance 50 MΩ 1.25 pF （diff） / 5 MΩ 2.5 pF
Bandwidth 100 MHz
Rise Time 3.5 ns
Max. Diff Test Input 130 V (50:1) / 1300 V (500:1)
Max. Input CAT II 1000 V
Input Cable Length 0.45 m
Output Cable Length 0.90 m
  • Only connect to a grounded (earthed) oscilloscope!
Probe
max. Bandwidth
100 MHz
max. Input Voltage
1300 V
Input Resistance
10 MΩ
Type
Oscilloscope
Active
Differential probe
Probe-Divider
50 : 1
500 : 1
1 year warranty

Nr: Micsig DP10013

Plus Shipping Costs
in Stock
€ 169.-
net (VAT Details)
€ 201.11
incl. 19% VAT

Micsig DP20003

1 Review

Active differential probe, switchable

Attenuation 200:1 / 2000:1
Input Impedance 50 MΩ 1.25 pF （diff） / 25 MΩ 2.5 pF
Bandwidth 100 MHz
Rise Time 3.5 ns
Max. Test Input 560 V (200:1) / 5600 V (2000:1)
Max. Input CAT II 1000 V
Input Cable Length 0.45 m
Output Cable Length 0.90 m
  • Only connect to a grounded (earthed) oscilloscope!
Probe
max. Bandwidth
100 MHz
max. Input Voltage
5600 V
Input Resistance
10 MΩ
Type
Oscilloscope
Active
Differential probe
Probe-Divider
200 : 1
2000 : 1
1 year warranty

Nr: DP20003

with FREE shipping within the EU! Shipping costs outside EU
in Stock
€ 239.-
net (VAT Details)
€ 284.41
incl. 19% VAT

Micsig DP750-100

Be the first to write a review

Active differential probe, switchable

Attenuation 50:1 / 500:1
Input
Impedance		 8 MΩ 1.25 pF （differential）
4 MΩ 2.5 pF （single ended to ground）
Bandwith 100 MHz
Rise Time 3.5 ns
Max. Test Input 75 V (50:1)
750 V (500:1)
Max. Input (grounded) CAT II 1000 V
Input Cablelength 0.15 m
Output Cablelength 1.0 m
  • Only connect to a grounded (earthed) oscilloscope!
Probe
max. Bandwidth
100 MHz
max. Input Voltage
750 V
Input Resistance
10 MΩ
Type
Oscilloscope
Active
Differential probe
Probe-Divider
50 : 1
500 : 1
1 year warranty

Nr: DP750-100

Plus Shipping Costs
in Stock
€ 179.-
net (VAT Details)
€ 213.01
incl. 19% VAT

Micsig CP2100A

7 Reviews

Current probe

  • Bandwidth 800 kHz
  • Rise Time ≤ 583 ns
  • Current Ranges
    • 10 A at 0.1 V/A sensivity
    • 100 A at 0.01 V/A sensivity
  • CAT II 600 V / CAT III 300 V
  • USB-powered
Probe
max. Bandwidth
800 kHz
max. Input Voltage
V
Input Resistance
Ω
Type
Oscilloscope
Active
Current Probe
1 year warranty

Nr: Micsig CP2100A

with FREE shipping within the EU! Shipping costs outside EU
in Stock
€ 227.-
net (VAT Details)
€ 270.13
incl. 19% VAT

Micsig CP2100B

7 Reviews

Current probe

  • Bandwidth 2.5 MHz
  • Rise Time ≤ 175 ns
  • Current Ranges
    • 10 A at 0.1 V/A sensivity
    • 100 A at 0.01 V/A sensivity
  • CAT II 600 V / CAT III 300 V
  • USB-powered
Probe
max. Bandwidth
2.5 MHz
max. Input Voltage
V
Input Resistance
Ω
Type
Oscilloscope
Active
Current Probe
1 year warranty

Nr: Micsig CP2100B

with FREE shipping within the EU! Shipping costs outside EU
in Stock
€ 315.-
net (VAT Details)
€ 374.85
incl. 19% VAT
