JBC NASE-2C

High end Nano Soldering and Desoldering Station of the JBC Premium Line for high-precision soldering jobs of delicate components. The JBC NANE is equipped with a 14W Nano Soldering Iron and 14W Nano Tweezers. The ergonomics, the very thin and flexible cable and the short distance tip-to-grip of the Nano Soldering Handle and the Nano Tweezers ensure greater accuracy and is ideal for delicate SMD soldering jobs.

Delivery including

  • Soldering Iron:

    • NT115-A (Nano Soldering Iron)
    • NP115-A (Nano Tweezers)
  • Cartridges:

    • C115101 (Conical Ø 0,1 mm)
    • C115103 (Conical Ø 0,3 mm)
    • 2x C115105 (Bend Ø 0,3 mm)
    • C115107 (Conical Ø 0,8 mm)
    • C115112 (Knife 2,5 x 3 mm)
    • 2x C115113 (Chisel 1,0 x 0,3 mm)
  • Tools:

    • 0016606 (Dispenser)
    • 009848 (Allan Key)
    • CL2466 (Brush)
    • CL6210 (Brass Wool)
    • Power cord
    • Manual (Englisch)

€ 1,303.05 incl. VAT

€ 1,095.- net

with FREE shipping within the EU!Shipping costs outside EU


Availability:
Picture: n/a

This article is currently in stock and can be shipped immediately.

EAN: 8427327457546

2 years warranty

30 days trial period

Made in Spain


Share on facebook
Google +1
Twitter

Description

High end Nano Soldering and Desoldering Station of the JBC Premium Line for high-precision soldering jobs of delicate components. The JBC NANE is equipped with a 14W Nano Soldering Iron and 14W Nano Tweezers. The ergonomics, the very thin and flexible cable and the short distance tip-to-grip of the Nano Soldering Handle and the Nano Tweezers ensure greater accuracy and is ideal for delicate SMD soldering jobs.

The NASE-C comes with the new function "Temperature Dynamic Profiles". This new functionality allows using dynamic profiles in order to control the temperature of the component during all the phases of the soldering process (preheating, soak, reflow), in accordance with IPC J-STD-001G Section 4.6, emulating the heating process in a reflow oven.

Special Features

Picture: Innovative Heating System

Innovative Heating System

The compact heating elements in the cartridges optimize heat transfer by reducing the thermal barriers. The fully integrated thermal sensor to the heater ensures an extremely quick temperature recovery.
The JBC NASE-2C increases the performance by using an intelligent algorithm in the heating control system.
Picture: JBC, the most efficient soldering process

JBC, the most efficient soldering process

Instead of other Soldering Manufactures, JBC NASE-2C allows a reduction of the temperature by at least 50ºC.
JBC NASE-2C stations only drop 35ºC (95ºF) where others drop as much as 70ºC (158ºF). Lowering the temperature reduces the risk of damaging components and improves the quality of soldering and desoldering.
Picture: JBC Sleep & Hibernation

JBC Sleep & Hibernation

The Sleep function automatically reduces tip temperature to 180ºC
when the iron is resting in the stand.
The JBC NASE-2C automatically goes into Hibernation when the set time in Sleep mode is finished. The power supply is cut off and tip keeps at room temperature.
The tool must be in the stand for the Sleep & Hibernation functions to work.
Picture: Longer Tip life

Longer Tip life

Tip life increases exponentially by using a lower tempearture for a shorter time, as shown in the graph. JBC tips last 5 times longer than other brands thanks to the Exclusive Heating System and the Intelligent Heat Management: Sleep & Hibernation functions.
Picture: Increased Productivity

Increased Productivity

Save time by using the quick cartridge extractor, which is available in all stands and compact stations. This system designed by JBC allows the user to change cartridges quickly and safely. Without switching the JBC NASE-2C off, you can carry out different soldering jobs.
Picture: PC communication and firmware updates via USB

PC communication and firmware updates via USB

All JBC NASE-2C soldering stations have a USB connector. The devices can be controlled by the JBC Open Manager software and for example temperature gradients can be recorded.
With the JBC Updater Software, Firmware updates can be transferred into the device. This keeps your soldering station also in the future up to date.

Technical Data

Specifications NASE-2C
Weight 2.450 kg (5.48 lbs)
Size 170 x 90 x 135 mm
Input fuse 0.2V
Output Peak Power 14W per tool
Temperature selection 90-450 ºC (190-840 ºF)
Idle temp. stability (still air) ±3ºC (±5.5 ºF)
Tip to ground resistance < 2 Ohm
Ambient operating temp. 10 - 40 ºC (50 - 104 ºF)
Communication connectors USB-A / USB-B / Pedal
Robot connector RJ12 (RS-232 Protokoll)
ESD safe checked
Package weight 2.990 kg (6.59 lbs)
Package dimensions 280 x 280 x 164 mm

JBC C115 Soldering Tips

JBC C115-101

Be the first to write a review

JBC C115101, CARTRIDGE CONICAL Ø0,1

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-103

Be the first to write a review

JBC C115103, CARTRIDGE CONICAL Ø0,3 S1

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-105

Be the first to write a review

JBC C115105, CARTRIDGE BENT Ø0,3

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-106

Be the first to write a review

JBC C115106, CARTRIDGE CONICAL Ø0,5

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-107

Be the first to write a review

JBC C115107, CARTRIDGE CONICAL Ø0,8

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-110

Be the first to write a review

JBC C115110, CARTRIDGE BENT Ø0,5

€ 33.20 incl. 19% VAT
€ 27.90 net (VAT Details)
10 pcs.: € 31.54 / € 26.50
50 pcs.: € 30.94 / € 26.-
Prices incl. 19% VAT / net

JBC C115-112

Be the first to write a review

JBC C115112, CARTRIDGE KNIFE 2,5X0,3

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-113

Be the first to write a review

JBC C115113, CARTRIDGE CHISEL 1X0,3

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-116

Be the first to write a review

JBC C115116, CARTRIDGE CHISEL 0,2X0,1

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC C115-118

Be the first to write a review

JBC C115118, CARTRIDGE BENT Ø0,1

€ 41.65 incl. 19% VAT
€ 35.- net (VAT Details)
10 pcs.: € 38.08 / € 32.-
50 pcs.: € 35.70 / € 30.-
Prices incl. 19% VAT / net

JBC Compact Line Accessories

JBC CLMS-B

Be the first to write a review

Automatic cleaner (Junior) of JBC. The CLMS-B cleans the tip in only 1 second, which means you save time and optimize production. The operator just needs to press the button of the opening with the tool.

Delivery including CLMS-A8 (Metal Brushes), 0015971 (AC Adapter) and Manual (English).

2 years warranty.

Datasheet
€ 294.53 incl. 19% VAT
€ 247.50 net (VAT Details)
with FREE shipping within the EU!
Shipping costs outside EU

JBC CLMB-PA

Be the first to write a review

Automatic cleaner (Senior) of JBC. The CLMB-PA cleans the tip in only 1 second, which means you save time and optimize production. It works by means of a sensor. The operator places the tip at the opening and two motorized non-metal brushes will clean it uniformly. the CLMB-PA also features a second position which facilitates vertical access of the tip. Ideal for robots.

Delivery including CLMB-P1 (Non-Metal Brush), 0014381 (AC-Adapter) and Manual (English).

2 years warranty.

€ 406.44 incl. 19% VAT
€ 341.55 net (VAT Details)
with FREE shipping within the EU!
Shipping costs outside EU

JBC CLMB-A

Be the first to write a review

Automatic cleaner (Senior) of JBC. The CLMB-A cleans the tip in only 1 second, which means you save time and optimize production. It works by means of a sensor. The operator places the tip at the opening and two motorized metal brushes will clean it uniformly. the CLMB-A also features a second position which facilitates vertical access of the tip. Ideal for robots.

Delivery including CLMB-A8 (Metal Brush), 0014381 (AC-Adapter) and Manual (English).

2 years warranty.

Datasheet
€ 388.77 incl. 19% VAT
€ 326.70 net (VAT Details)
with FREE shipping within the EU!
Shipping costs outside EU

JBC CLMS-A8

Be the first to write a review

Motorized Metal Cleaning Brushes Ø 34mm from JBC for the CLMS Junior Tip Cleaner.

Delivery including Manual (English).

JBC CLMB-A8

Be the first to write a review

Motorized Metal Cleaning Brushes Ø 34mm from JBC for the CLMB-A Senior Tip Cleaner.

Delivery including Manual (English).

JBC CLMB-P1

Be the first to write a review

Motorized Non-Metal Cleaning Brushes Ø 34mm from JBC for the CLMB-A Senior Tip Cleaner. When used properly, the non-metal brushes will have a longer life than the metal ones.

Delivery including Manual (English).

JBC S0354

Be the first to write a review

Cleaning Sponge 36 x 69 mm from JBC. The sponge is the softest cleaning method to eliminate excess in any soldering or rework job. The S0354 fits in every Tip Cleaner of JBC.

JBC CL6205

Be the first to write a review

Inox Wool from JBC is a stronger cleaning method than brass wool.

Delivery including Manual (English).

JBC CL6210

Be the first to write a review

Brass Wool from JBC is a very effective cleaning method. The CL6210 leaves a small layer of solder on the tip preventing oxidation between cleaning and rewetting.

Delivery including Manual (English).

JBC CL6220

Be the first to write a review

Metal Cleaning Brush from JBC.

Delivery including Manual (English).

JBC CL6217

Be the first to write a review

Mini Cleaning from JBC.

Delivery including Manual (English).

JBC TT-A

Be the first to write a review

Tip Tinner from JBC is a chemical system to clean and retin the tip at te same time.

Delivery including Manual (English).

Datasheet
