Siglent SPS5000X

Name: Siglent SPS5165X
Brand: Siglent
SKU: 723497646314
Availability: InStock
Rating: 5.0 (2 reviews)

The SPS5000X Series is a programmable Switching DC Power supply series that provides a wide range of output power using single channel and multi channel output configuration s coupled with constant power capability. The series of power supplies include 16 models with voltages to 160 VDC and power to 1080 W.

The SPS5000X supplies can be connect ed in series 2 units or in parallel 3 units to meet the requirements of 0-320V and 0-270A, with a maximum combin ed power of 3240W.

The SPS5000X Series has a high brightness 2.4 inch OLED display, a user friendly human computer interface that enable easy control and performance monitoring.

The SPS5000X provides high resolution voltage and current settings, adjustable slew rates, list sequence programming from the front panel or over the standard LAN/ USB interface, analog control, and over voltage, current, power, and temperature protection .

These features mak e the series an ideal choice for a variety of demanding markets , including Commercial Industrial Education, Energy and Power Generation, laboratory general testing, the LED lighting industry, and automotive electronics.

Models	channel	channel	channel	Max. Total Power
SPS5041X	0 to 40 V / 0 to 30 A			360 W
SPS5042X	0 to 40 V / 0 to 60 A			720 W
SPS5043X	0 to 40 V / 0 to 90 A			1080 W
SPS5044X	0 to 40 V / 0 to 30 A	0 to 40 V / 0 to 30 A		720 W
SPS5045X	0 to 40 V / 0 to 30 A	0 to 40 V / 0 to 30 A	0 to 40 V / 0 to 30 A	1080 W

Models	Channel	Channel	Channel	Max. Total Power
SPS5051X	0 to 50 V / 0 to 10 A			180 W

Models	Channel	Channel	Channel	Max. Total Power
SPS5081X	0 to 80 V / 0 to 15 A			360 W
SPS5082X	0 to 80 V / 0 to 30 A			720 W
SPS5083X	0 to 80 V / 0 to 45 A			1080 W
SPS5084X	0 to 80 V / 0 to 15 A	0 to 80 V / 0 to 15 A		720 W
SPS5085X	0 to 80 V / 0 to 15 A	0 to 80 V / 0 to 15 A	0 to 80 V / 0 to 15 A	1080 W

Models	Channel	Channel	Channel	Max. Total Power
SPS5161X	0 to 160 V / 0 to 7.5 A			360 W
SPS5162X	0 to 160 V / 0 to 15 A			720 W
SPS5163X	0 to 160 V / 0 to 22.5 A			1080 W
SPS5164X	0 to 160 V / 0 to 7.5 A	0 to 160 V / 0 to 7.5 A		720 W
SPS5165X	0 to 160 V / 0 to 7.5 A	0 to 160 V / 0 to 7.5 A	0 to 160 V / 0 to 7.5 A	1080 W
