Description
High end infrared Preheater of JBC for multilayer PCBs. The JBC PHNE provides a homogeneous heat dissipation for an optimal result. The PHNE is equipped with a PCB Support, which provides 3 adjustable heights.
Technical Data
| Specifications | PHNE-2KA |
|---|---|
| Weight | 3.100 kg (6.83 lbs) |
| Size | 179 x 165 x 42 mm |
| Voltage | 230V |
| Input fuse | 4A T |
| Power | 300W |
| Heating Area | 108 x 70 mm (1 Zone) |
| Temperature Range | 50 to 250ºC (120 to 482ºF) |
| Temperature Measurement: | Thermocouple type K |
| JBCset Temperature Profiles: | 3 profiles ( 2, 3 or 4 steps) |
| User Temperature Profiles: | 20 (up to 6 steps for each) |
| Maximum work time: | 600 min |
| Package weight | 4,200 kg (9.26 lbs) |
| Package dimensions | 280 x 280 x 164 mm |
