Name: Rigol DP822
Brand: Rigol
Availability: InStock
Rating: 4.93 (46 reviews)

Description

The Rigol DP800 are programmable laboratory power supplies with 1 to 3 outputs and a maximum power output of 200 W.

Like all Rigol devices, the Rigol DP822 features a very well constructed and easy to use interface, which also offers comprehensive ease-of-use functions, such as programmable voltage curves. The menu has an intuitive structure.

The Rigol DP822 features a relative large (8.9 cm / 3.5") and easy to read TFT monochrome display. In addition to the normal digital displays for voltage, current, and power, these values can also be displayed as signal curves.

A timer control can be used to set the output signal to different values in up to 2048 steps.

Quick comparision	DP811 / DP811A	DP813 / DP813A	DP821 / DP821A	DP822 / DP822A	DP831 / DP831A	DP832 / DP832A
Voltage / Current CH1	0 - +20 V / 0 - 10 A oder 0 - +40 V / 0 - 5 A	0 - +8 V / 0 - 20 A oder 0 - +20 V / 0 - 10 A	0 - +60 V / 0 - 1 A	0 - +20 V / 0 - 5 A	0 - +8 V / 0 - 5 A	0 - +30 V / 0 - 3 A
Voltage / Current CH2			0 - +8 V / 0 - 10 A	0 - +5 V / 0 - 16 A	0 - +30 V / 0 - 2 A	0 - +30 V / 0 - 3 A
Voltage / Current CH3					0 - -30 V / 0 - 2 A	0 - +5 V / 0 - 3 A

You will find the specifications of the DP800 series here.

	A-Models	Basic Models
Voltage Resolution	1 mV	10 mV (1 mV with High-Resolution Option)
LAN, RS232 and Digital IO Ports	Included	Option
Online Monitoring & Analysis Function	Included	Option
Display	3.5" (8.9 cm) Color-TFT	3.5" (8.9 cm) Monochrome TFT

Special Features

The Rigol DP832A can be controlled remotely with SCPI commands through a variety of interfaces. The following interfaces are available:

USB
LAN
GPIB (optional)

Control of the device can be integrated into your own applications, or by using LabView via these interfaces.

Specifications

Specifications	Rigol DP811
Outputs	1 output with 2 selectable ranges
Output	0 to 20 V/DC with max. 10 A or 0 to 40 V/DC with max. 5 A
Ground Sharing	Output 1 sole GND
Output Power (max.)	200 W
Overtemperature shut down	55 °C
Working Temperature	0 °C to 40 °C
Cooling Method	Fan cooling

Output Voltage	Output Range 1	Output Range 2
Output Voltage	0 to 20 V/DC	0 to 40 V/DC
Accuracy	±0.05% + 10 mV	±0.05% + 10 mV
Resolution	10 mV (1 mV with High Res. option)	10 mV (1 mV with High Res. option)
Overvoltage Protection	100 mV to 22 V	100 mV to 44 V
Load Regulation	< 0.01% + 2 mV
Line Regulation	< 0.01% + 2 mV
Ripple and Noise	< 350 μV rms / 2 mVpp

Output Current	Output Range 1	Output Range 2
Output Current (max.)	10 A	5 A
Accuracy	±0.1% + 10 mA	±0.1% + 10 mA
Resolution	10 mA (1 mA with High Res. option)	10 mA (1 mA with High Res. option)
Overcurrent Protection	0.1 A to 11 A	0.1 A to 5.5 A
Load Regulation	< 0.01% + 250 μA
Line Regulation	< 0.01% + 250 μA
Ripple and Noise	< 2 mA rms

Programmable power supply	Rigol DP811
Display	8.9 cm (3.5") WVGA-Monochrome-LCD
Resolution	320 × 240 Pixel
Additional Interfaces	USB host for connecting USB sticks to store settings USB device for connection to a PC LAN for use on a network (LXI) (option) RS232 (option) GPIB (IEE-488, General Purpose Interface Bus, only with optional adapter) Separate ground connection Digital IO Ports (option)
Dimensions (W × H × D)	23.9 cm × 15.7 cm × 41.8 cm (9.41" × 6.18" × 16.46")
Weight	9.0 kg (19.84 lbs)
Supported operating systems	no software available, but interfacing with other systems such as LabView is possible.
Input	230 V/AC, 115 V/AC or 100 V/AC (adjustable)
