The SIGLENT SNA6000A series of Vector Network Analyzers have a frequency range of 100 kHz to 13.5 GHz and 100 kHz to 26.5 GHz, which support 2/4-port scattering parameter, differential-parameter, and timedomain parameter measurements. The Siglent SNA6122A are effective instrumentation for determining the Q-factor, bandwidth, and insertion loss of a filter, They feature impedance conversion, movement of measurement plane, limit testing, ripple test, fixture simulation, and adapter removal/insertion adjustments.
The VNAs have five sweep types: Linear-Frequency mode, Log-Frequency mode, Power-Sweep mode, CW-Time mode, and Segment-Sweep mode. The SNA6000A series VNAs also support scattering-parameter correction of SOLT, SOLR, TRL, Response, and Enhanced Response for increased flexibility in R&D and manufacturing applications.
Purchase a new SNA6000A Series instrument and select a free analysis option for your application. Valid until December 31, 2024!
Select one of the following options and send us an enquiry to service@batronix.com!
Model Overview | SNA6022A | SNA6122A | SNA6024A | SNA6124A | SNA6032A | SNA6132A | SNA6034A | SNA6134A |
---|---|---|---|---|---|---|---|---|
Frequency range | 100 kHz - 13.5 GHz | 100 kHz - 13.5 GHz | 100 kHz - 13.5 GHz | 100 kHz - 13.5 GHz | 100 kHz - 26.5 GHz | 100 kHz - 26.5 GHz | 100 kHz - 26.5 GHz | 100 kHz - 26.5 GHz |
Ports | 2 | 2 | 4 | 4 | 2 | 2 | 4 | 4 |
Frequency resolution | 1 Hz | 1Hz | 1H | 1Hz | 1Hz | 1Hz | 1Hz | 1Hz |
Dynamic range | 135 dB | 135 dB | 135 dB | 135 dB | 135 dB | 135 dB | 135 dB | 135 dB |
Setting range of output level | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm | -55 dBm ~ +10dBm |
Front panel jumper interface | ||||||||
Video output (HDMI) | ||||||||
Touch-Display | ||||||||
Scattering-parameter measurement | ||||||||
Differential-parameter measurement | ||||||||
Limit test | ||||||||
Impedance conversion |
You will find the specifications of the SNA6000A series here.
