Name: Keysight U1273A
Brand: Keysight
Availability: Discontinued
Rating: 5.0 (1 reviews)

Description

All models are ergonomically built providing useful functions such as ZLOW, which eliminates stray voltages, and Smart Ohm that minimizes false readings from residual voltage induced by leakage current. All of this is designed into a case that fulfills the needs of today's industrial handheld users.

30,000-count resolution
Measure up to 1000 V AC and DC
Measure up to 10 A (20 A for 30 s)
Resistance, diode test, temperature, capacitance
Low Impedance mode and Low Pass Filter
Peak detection of up to 250 μs
Continuity test with beeper and backlight
Seven readings/s measurement rate for voltage and current
Smooth function for accurately stable readings
Up to 10.000 points internal memory for data logging
Bluetooth wireless connectivity with optional U1177A Bluetooth
PC connectivity with optional U1173A IR-USB cable
IP 54 certified – water and dust resistant
CAT III 1000 V, CAT IV 600 V safety rating
Up to 3000m operating altitude

Model	U1272A	U1273A
Display resolution	LCD	OLED
Backlight		N/A
True RMS
Basic dcV accuracy	0.05% + 2 counts	0.05% + 2 counts
continuity, diode test
temperature
capacitance
Low pass filter
Logging memory	10,000 points	10,000 points
Over-voltage safety protection	CAT III 1000 V, CAT IV 600 V	CAT III 1000 V, CAT IV 600 V
Water and dust ingress protection	IP 54	IP 54
Battery life	Up to 300 hours 4X AAA Alkaline	Up to 60 hours 4X AAA Alkaline
