Description

The Rigol DS6062 is a very high quality two channel digital storage oscilloscope. It offers a real-time sample rate of up to 5 GSa/s and a bandwidt of up to 600 MHz h.

This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The DS6062 has a refresh rate of up to 180.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.

Other advantages: 10.1" color LCD, bright and vivid waveform display; versatile trigger modes: i.e. slope, alternative, rise&fall edge, enables users to stabilize the signal more easily. In economic context, the DS6062 clearly has the highest performance standard and the largest number of functions, making it a top of the range oscilloscope.

Model	DS6062	DS6064	DS6102	DS6104
Bandwidth	600 MHz	600 MHz	1 GHz	1 GHz
Max. Sample rate	5 GSa/s	5 GSa/s	5 GSa/s	5 GSa/s
Waveform Capture Rate	180000 wfms/s	180000 wfms/s	180000 wfms/s	180000 wfms/s
Memory (standard)	140 Mpts	140 Mpts	140 Mpts	140 Mpts
Channels	2	4	2	4

Special Features

Innovative wider display

It is possible to observe up to 14 divisions on the innovative extra wide 10.1" display with a resolution of 800x480 pixels. Using the "Waveform Finder" it is easy to find a specific part of the recorded waveform. The huge memory can store up to 140.000.000 points.

Very high capture rate

Due to the very high waveform capture rate of the DS6000 series oscilloscopes it is possible to capture up to 180.000 waveforms per second.

Hardware Signal Filter (unfiltered)

The device has several hardware filters to remove noise from the signal. Selectable filters are low pass, high pass, band pass and a band reject filter. The signal with significant noise.

Hardware Signal Filter (filtered)

The hardware filters are a lot faster than the regular data post processing filters (DSP - Digital Signal Processing). The cleaner waveform with hardware filtering.

Advanced Math

The DS6000 series oscilloscopes comes with a modern and advanced math system which allows to solve complicated signal calculations quite simply using user defined formulas.

Auto measurements with statistics

The oscilloscope measures up to five parameters like rise- and fall-time, amplitude, pulse width, duty cycle and many more simultaneously and shows statistics for every parameter (max- , min- and average values).

Serial Bus Decoding

Serial data packages of different serial bus systems can be decoded. Supported protocols are: Parallel (standard), RS232/UART (option), I²C (option), SPI (option) and CAN (option). The optional decoding modules can be bought separately, see accessories tab on this site.

Masked Pass/Fail-Tests

Pass/fail testing can be used for troubleshooting in various environments like communication networks. Features: User defined masks, Pass/Fail counts, Stop on Fail, Fail Alarm

Specifications

General Data	Digital Oscilloscope Rigol DS6062
Display	10,1" WVGA-Color-LCD
Resolution	800 × 480 Pixel
Interface	2x USB-host for i.e. USB sticks USB-Device for a PC connection or USB Pict-Bridge printerinterface LAN for network connectivity (LXI compilant) GPIB (IEE-488, General Purpose Interface Bus) using the optional USB-GPIB Module Trigger- and Calibrationoutput 10 MHz reference clock In-/Out VGA interface to connect to an external monitor or projector
Size (W × H × D)	39.5 cm × 25.5 cm × 12.5 cm 15.55" × 10.04" × 4.92"
Weight	4.67 kg 10.3 lbs
Supported operation systems	Windows XP (32Bit + 64Bit) Windows Vista (32Bit + 64Bit) Windows 7 (32Bit + 64Bit)

Oscilloscope Functions	Digital Oscilloscope Rigol DS6062
Channels	2
Real-time sample rate	5 GSa/s realtime
Bandwidth	600 MHz
Sampling Modus	Normal, average, peak detect
Mathematics	userdefined, FFT (Fast Fourier Transform)
FFT windows	Rectangle, Hanning, Hamming, Blackman
Signal Bus Decoding	Parallel, RS232/UART, I²C, SPI

Signal	Digital Oscilloscope Rigol DS6062
Input	DC/AC coupling, up to 300 Vrms CAT I
Real-time sample rate	up to 5 GSa/s realtime
Time base	1 ns/div to 50 s/div
Memory	140 Mpts (1 Channel)
Filter	Hardware LPF, HPF, BPF and BRF

Vertical	Digital Oscilloscope Rigol DS6062
Analog digital converter (A/D)	With the resolution of 8 bits, make sampling on both channels synchronously.
Sensitivity range (V/div)	2 mV/div to 5 V/div
Offset range	2 mV/div to 5 V/div ± 40 V

Trigger	Digital Oscilloscope Rigol DS6062
Trigger	Channel, Ext, EXT/5
Signal system and line/field frequency (Video triggering mode)	PAL, NTSC, SECAM
Triggerfunctions	Edge, Pulse, Slope, Video, Pattern, RS232/UART, I²C, SPI, CAN, USB

Measurement	Digital Oscilloscope Rigol DS6062
Cursor measurement	Manual, Track and Auto Measure modes
Auto measurement	Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall time, Positive Width, Negative Width, Positive Duty Cycle, Negative Duty Cycle, Delay1-2 (rise), Delay1-2(fall)
